Mold size (mm)		Net weight
L × W	H	89.14kg
250x250	241	89.14kg

OEM / ODM ： Multi Cavity Injection Mold & Speaker bracket (1*8) No.22686

Precision Injection Molding

Hot Runner Injection Molding

Cold Runner Injection Molding

Single Cavity Injection Mold

Insert Injection Molding

ABS Injection Molding

Polypropylene Injection Molding

Multi Cavity Injection Mold

Double Injection Molding

Metal Stamping Molds

OEM / ODM ： Multi Cavity Injection Mold & Speaker bracket (1*8) No.22686

multi cavity injection molding

64 cavity mold layout

multi cavity injection moulding

This is a two-plates mold made of high quality steel billet, LKM standard, side gate + direct gate; with no stripper plate, so manual degating is required

The part material is PC+ABS; part size is 15.10 X 14.53 X 1.25mm and part weight is only 0.1g

harden the cavity and core with 1*8/S136 to improve the hardness and anti-corrosion performance; surface EDM with VDI 21# (Ra1.12) to be semi-gloss, smoother for easy molding and demolding
